6 Inch Bits (Halco)

6 Inch Bits (Halco)

Halco Rock Tools design and manufacture to exacting standards, Halco DTH hammers deliver outstanding performance, productivity and longevity. Customers also enjoy the versatility and variety, allowing the use of Halco DTH hammers on a wide range of rock-drilling applications. All Halco drill bits have superb performance and benefit from a long life span.

Halco 6 Overview

Diameter (Inches)	Face Design	Buttons Type	Qty & Dia	Oversize	Weight (kg)
6	Convex	Dome	16 x 16mm		23.5
6-1/2	Convex	Dome	19 x 16mm		26
6-3/4	Flat	Dome	19 x 16mm		26
7	Convex	Dome	18 x 16mm	Y	30
7-7/8	Convex	Dome	20 x 16mm	Y	34
8-7/8	Convex	Dome	26 x 16mm	Y	42
9-5/8	Convex	Dome	27 x 16mm	Y	49

DHD360 Overview

Diameter (Inches)	Face Design	Buttons Type	Qty & Dia	Oversize	Weight (kg)
6	Convex	Dome	20 x 16mm		25
6	Concave	Dome	17 x 16mm		25.7
6-1/2	Concave	Dome	18 x 16mm		25.5
6-1/2	Convex	Dome	20 x 16mm		26
6-3/4	Convex	Dome	6 x 16mm / 13 x 18mm		16.16
7	Concave	Dome	18 x 16mm		27.3
7-1/2	Concave	Dome	24 x 16mm	Y	30
7-5/8	Convex	Dome	21 x 16mm	Y	34.5
8	Concave	Dome	31 x 16mm	Y	35.2
8-5/8	Concave	Dome	22 x 20mm	Y	40
8-5/8	Flat	Dome	15 x 18mm	Y	40
9-1/2	Flat	Dome	18 x 16mm / 10 x 20mm	Y	50

QL60 Overview

Diameter (Inches)	Face Design	Buttons Type	Qty & Dia	Oversize	Weight (kg)
6-1/8	Concave	Dome	20 x 16mm		23.2
6-1/2	Concave	Dome	18 x 16mm		24.4
6-1/2	Convex	Dome	20 x 16mm		23.85
6-1/2	Flat	Dome	22 x 18mm		23.9
6-3/4	Convex	Dome	19 x 18mm		25.3
6-3/4	Concave	Dome	18 x 16mm		25.1
6-3/4	Convex	Dome	9 x 13mm / 19 x 18mm		25.35
7	Concave	Dome	8 x 20mm / 11 x 16mm	Y	26.2
7-1/2	Concave	Dome	24 x 16mm	Y	31.7
8	Concave	Dome	31 x 16mm	Y	34.1
